PW400

The PW400 system is a four sided mechanically glazed engaged curtainwall, that is, expressed horizontal transom elements and vertical mullion elements. The PW Series Suites have been extensively used and proven in New Zealand and our export markets since 1985.



The weathering design of these suites follows recognised international curtainwall design principles - rainscreen pressure equalisation and system drainage - which requires primary and secondary weathering. The rainscreen acts as a primary water-stop, the second airseal and cavity acts as a backup to collect and drain away any water that manages to penetrate the primary rainscreen barrier.

All internal cavities of the system are designed to be pressure equalised (ie no pressure differential between the outside face and any internal cavity). This feature allows the water which penetrates the rainscreen to drain freely back to the exterior. The rear air seal is critical to the system's weathering performance as air infiltration acts as the medium which transports water through to the building's interior, i.e. it is the prime cause of any leakage.



PERFORMANCE/SPECIFYING

We work with the largest facade testing facility in New Zealand where we test our systems and custom designed suites to ensure compliance with the below codes or project specific requirements:

  • AS/NZS1170 (Structural Design Actions)
  • NZS4223 (Glazing in Buildings)
  • NZS/AS4284:2008 (Water / Air Pressure/ Air Leakage - Meets and exceeds minimum requirements)

All the Woods Glass suites are independently laboratory tested to IANZ (International Accreditation New Zealand). Test certificates are available on request.

CLEANING/MAINTENANCE

Maintaining glass, metals and stone are all particular to the environment that they are placed in, e.g. marine, environmental pollution, exposure to natural washing, etc.

It is recommended by almost all material suppliers that building washing should occur every 3-6 months to prevent staining to glass and environmental pollutants from corroding metals and to maintain the material warranties.

A full maintenance manual is provided on completion of a project for all the elements integrated within a project.

RANGE

Sizing of modules is generally only limited on the project design requirements, economic considerations, transport and site crane installation limitations. We would be happy to discuss what these might be on your project.

The PW400 is available in various mullion sizes to suit your project: 75mm / 100mm / 150mm / 200mm with the ability where neccesary to structurally supplement the sections where the suite is exposed to high floor to floor spans or high wind zones, thus potentially reducing the need for additional primary or secondary structure to be provided by the Main Contractor.
